Fixed Mount Barcode Scanners

The new DS2100N industrial laser bar code reader leverages Datalogic Automation’s 40-year tenure in 1D bar code reading, satisfying the demanding application needs of warehousing, shop floor and OEM applications. Equipped with limitless connectivity options including PROFINET, EtherNet/IP, and Ethernet TCP/IP communication protocols, the DS2100N is the optimal choice for short reading distances.

DS8110 is the new bar code reader offering top class reading performance at any operative conditions, designed to satisfy the most demanding applications in the Parcel Sorting and Baggage Handling applications. Combining 30+ years experience and the most advanced technologies, DS8110 sets a new standard in T&L applications offering unique features and benefits.

DX8210 is Datalogic’s new high performance laser bar code reader purpose built to offer to offer top reading performance combined and
ease of use to End User and System Integrators specialized in the Transport and Logistics market. Thanks to its unique design, DX8210 offers an ALL-IN-ONE solution for omnidirectional reading stations. This single device is capable of reading codes at any orientation on the conveyor.

With the benefits of state-of-the-art technology and innovative optic design, DX8210 can cover a wide conveyor and large depth of field to satisfy demanding applications. A high scan rate (1000 scans/sec) allows DX8210 to work perfectly on high speed conveyors for mass production. Thanks to its ALL-IN-ONE architecture, DX8210 offers unmatchable ease of installation and ease of use. In just a few minutes, readers can be installed above the conveyor and the onmi-station is ready to work.

Matrix 410N™ is an industrial 2D imager for traceability applications in material handling and logistic environments.
Matrix 410N™ is equipped with a ultra-fast image sensor, scanning at 2.0 MPixels, with a frame rate of 45 fps. Ethernet connectivity is embedded, including standard communication services (TCP/IP, HTTP, FTP) and the most common industrial fieldbuses, as PROFINET IO, ETHERNET/IP, MODBUS TCP. Matrix 410N is flexible, easily configurable as single device reading station or in a multiple device layout, in order to scan over larger areas or multiple sides.

Matrix 410N offers image saving functions for reading cases review (as No Reads). Up to 3.000 images can be stored on board or transfer to an external FTP clients. Matrix 410N is “ease of use”: the DL.CODE software enables graphical setup and supports in-line monitoring functionalities, including live image display, reading statistics and diagnostics. The embedded laser aimer and the patented Green Spot – projected into the scanning area – permit to user a quick scanning area determination and to easily acknowledge a reading without any external accessory or software.

The Matrix 300N™ with 1.3 and 2 Megapixel high resolution sensors, is an ultra-compact image-based barcode reader with outstanding performance and the smallest form factor; the ideal solution for Automotive, Electronics, Intralogistics, Food & Beverage, Packaging, Document Processing and Medical applications. The Matrix 300N allows an easy and effective focus control for high reading flexibility because of the manual focus adjustment and the Liquid Lens technology for an electronic remote focus control.

The innovative lighting solution with an integrated flexible illumination system makes the Matrix 300N imager perfect for reading barcodes marked with DPM (Direct Part Marking) resulting in optimal illumination on normal, etched, reflective or textured surfaces. The Matrix 300N 2MP high power 10 LEDs illuminator is suitable for long range reading distances and the multi LED-chain illuminator with diffuser is very effective in barcode reading on flat surfaces with machining flaw.



Matrix 120™ is the smallest ultra-compact industrial 2D imager in the market that fits into any integration space and embeds Ethernet connectivity.

The Matrix 120 is the perfect solution when small dimension, simple integration and performance are the key drivers. This makes the Matrix 120 the ideal product for OEM customers: Chemical/Biomedical industry and Print & Apply applications. Additionally, this imager is perfect for entry level applications in the Factory Automation arena: Electronics, Packaging and Food/Beverage.

The Matrix 120 is available in different models, including a WVGA sensor for standard applications or a 1.2 MP sensor for high resolution barcodes. Moreover, the wide-angle version makes the Matrix 120 the perfect solution for proximity reading and with the polarized model a 90° mounting is possible also over reflecting surfaces.

The Matrix 120 features the top industrial grade parts in its class (IP65 and 0-45 ºC / 32 – 113 ºF), with ESD safe models for applications in the electronic industry and a glass-free reading window, suitable for the Food and Beverage environment.

As part of the full Matrix series, the Matrix 120 leads the market for customer ease of use because of DL.CODE™ configuration software, X-Press™ button and intuitive HMI.
